Image: Gray code rotary encoder 13-track opened

Kids Encyclopedia Facts
Original image ‎(1,135 × 2,175 pixels, file size: 710 KB, MIME type: image/jpeg)

Description: A Gray code absolute rotary encoder with 13 tracks. At the top can be seen the housing, interrupter disk, and light source; at the bottom can be seen the sensing element (reflective, marked 'OPTOLAB') and support components. This encoder was removed from a machine after water ingress caused the gray code tracks to lift off.
Title: Gray code rotary encoder 13-track opened
Credit: Own work
Author: Mike1024
Permission: Public domainPublic domainfalsefalse I, the copyright holder of this work, release this work into the public domain. This applies worldwide. In some countries this may not be legally possible; if so: I grant anyone the right to use this work for any purpose, without any conditions, unless such conditions are required by law.
