Image: Incremental directional encoder
No higher resolution available.
Incremental_directional_encoder.gif (387 × 225 pixels, file size: 124 KB, MIME type: image/gif, looped, 20 frames, 16 s)
Description: Example of two-row rotary encoder for speed and direction detection. Basically a 2-bit Gray code pattern. Generated by Matt Hercules
Title: Incremental directional encoder
Credit: Transferred from en.wikibooks to Commons.
Author: Sidehack at English Wikibooks
Usage Terms: Public domain
License: Public domain
Attribution Required?: No
