Image: 'Black Prince' (1816); 'Melville' (1817); 'Hawke' (1820); 'Wellesley' (1815) RMG J2761

Description: Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for 'Black Prince' (1816), 'Melville' (1817), 'Hawke' (1820) and 'Wellesley' (1815), all 74-gun Third Rate, two-deckers, based on the design of the captured Danish 74-gun 'Christian VII'. Note that the 'Wellesley' was originally of this design, but was changed to follow the lines of the 'Cornwallis' (1813) of the Armada/Conquestadore/Vengeur class. Signed by William Rule [Surveyor of the Navy, 1793-1813] and Henry Peake [Surveyor of the Navy, 1806-1822]. lines & profile Admiralty Collection, Ship Plans
Title: 'Black Prince' (1816); 'Melville' (1817); 'Hawke' (1820); 'Wellesley' (1815)
Credit: https://collections.rmg.co.uk/collections/objects/80746.html
Author: Unknown authorUnknown author
Permission: The original artefact or artwork has been assessed as public domain by age, and faithful reproductions of the two dimensional work are also public domain. No permission is required for reuse for any purpose. The text of this image record has been derived from the Royal Museums Greenwich catalogue and image metadata. Individual data and facts such as date, author and title are not copyrightable, but reuse of longer descriptive text from the catalogue may not be considered fair use. Reuse of the text must be attributed to the "National Maritime Museum, Greenwich, London" and a Creative Commons CC-BY-NC-SA-3.0 license may apply if not rewritten. Refer to Royal Museums Greenwich copyright.
Usage Terms: Public domain
License: Public domain
Attribution Required?: No
