Image: Basic Mass Spectrometer
Size of this preview: 800 × 407 pixels. Other resolutions: 320 × 163 pixels | 1,162 × 591 pixels.
Original image (1,162 × 591 pixels, file size: 87 KB, MIME type: image/jpeg)
Description: Simple representation of how an atomic mass spectrometer is set up.
Usage Terms: Public domain
