Image: Blackbody efficacy 1000-16000K
Size of this PNG preview of this SVG file: 512 × 287 pixels. Other resolution: 320 × 179 pixels.
Original image (SVG file, nominally 512 × 287 pixels, file size: 42 KB)
Description: Luminous efficacy of a blackbody radiator within 1000 to 16000 Kelvins. The plotted data are derived by integration of Planck function convolved via the CIE 1924 photopic V(λ) luminosity function (equivalent to the y function of the CIE 1931 color-matching functions). Data points are interpolated as cubic splines by gnuplot. The luminous efficacy is given by the left scale and the grid. The right scale shows the luminous efficiency in percent with 100% referring to the visual maximum for monochromatic light at 555 nm and 683 lm/W efficacy.
Usage Terms: Public domain
