Image: Failed SMPS controller IC ISL6251
Size of this preview: 800 × 600 pixels. Other resolutions: 320 × 240 pixels | 1,080 × 810 pixels.
Original image (1,080 × 810 pixels, file size: 302 KB, MIME type: image/jpeg)
Description: Voltage with wrong polarity has caused massive overheating of the chip, consequently melting the plastic casing.
Title: Failed SMPS controller IC ISL6251
Credit: Own work
Author: Petteri Aimonen
Usage Terms: Creative Commons Zero, Public Domain Dedication
License: CC0
License Link: http://creativecommons.org/publicdomain/zero/1.0/deed.en
Attribution Required?: No
