Image: German Gymnasium London Trussed Roof Detail
Size of this preview: 800 × 600 pixels. Other resolutions: 320 × 240 pixels | 2,272 × 1,704 pixels.
Original image (2,272 × 1,704 pixels, file size: 924 KB, MIME type: image/jpeg)
Description: Detail of the revolutionary trussed roof structure of the German Gymnasium at St Pancras London showing cast iron fillets fitted to the laminated timber supports
Title: German Gymnasium London Trussed Roof Detail
Credit: Own work
Author: Ray Butt
Usage Terms: GNU Free Documentation License
License: GFDL
License Link: http://www.gnu.org/copyleft/fdl.html
Attribution Required?: Yes
