Image: Gusset
No higher resolution available.
Description: This image, from the National Transportation Safety Board's Office of Research and Engineering, shows a fracture in a gusset plate that played a key role in the collapse of the Interstate 35W bridge. (National Transportation Safety Board photo)
Title: Gusset
Credit: http://minnesota.publicradio.org/display/web/2008/07/31/bridgeinvestigation_update/
Author: NTSB
Usage Terms: Public domain
License: Public domain
Attribution Required?: No
