Image: SakiaSchematicWater
Size of this PNG preview of this SVG file: 407 × 370 pixels. Other resolution: 264 × 240 pixels.
Original image (SVG file, nominally 407 × 370 pixels, file size: 20 KB)
Description: Sakia wheel for lifting water, schematic of assumed construction according to figures 26 and 27 provided by P. Fraenkel at https://www.fao.org/4/ah810e/AH810E05.htm#Fig.%2026 and the way water is lifted towards assumed triangular exit openings.
Usage Terms: Public domain
