Image: Sine voltage
Size of this PNG preview of this SVG file: 575 × 599 pixels. Other resolution: 230 × 240 pixels.
Original image (SVG file, nominally 765 × 797 pixels, file size: 1 KB)
Description: A sinodial voltage. 1 = Amplitude (peak), 2 = Peak-to-peak, 3 = RMS, 4 = Wave period
Usage Terms: Public domain
