Image: TI 502 schematic
Size of this preview: 800 × 522 pixels. Other resolutions: 320 × 209 pixels | 1,007 × 657 pixels.
Original image (1,007 × 657 pixels, file size: 11 KB, MIME type: image/png)
Description: Schematic of Texas Instruments 502 astable multivibrator - the first silicon IC sold on the open market. It mixed up some monolithic features with hybrid wiring.
Title: TI 502 schematic
Credit: Own work
Author: Retired electrician
Usage Terms: Public domain
License: Public domain
Attribution Required?: No
