Image: VFPt flat magnets gap
Size of this PNG preview of this SVG file: 600 × 600 pixels. Other resolution: 240 × 240 pixels.
Original image (SVG file, nominally 800 × 800 pixels, file size: 66 KB)
Description: Drawing of two homogeneously magnetized flat cylindrical magnets with exactly computed magnetic field lines for the case of vanishing susceptibility (
μ
r
≈ 1
{\displaystyle \mu _{r}\approx 1}
). The two magnets are aligned on top of each other along the cylinder axis and with a narrow gap in-between. This configuration is often used as a dipole magnet to create a strong and roughly uniform magnetic field in the gap, for instance in cyclotrons.
Author: Geek3
Usage Terms: Creative Commons Attribution-Share Alike 3.0
License: CC-BY-SA-3.0
License Link: http://creativecommons.org/licenses/by-sa/3.0/
Attribution Required?: Yes
