Image: ATVtoISS
No higher resolution available.
Description: Orbital rendezvous. 1/ Both spacecraft must be in the same orbital plane. Iss flies in a higher orbit (lower speed), ATV flies in a lower orbit and catches up with ISS. 2/At the moment when the ATV and the ISS make an alpha angle (about 2°), the ATV crosses the elliptical orbit to the ISS. https://www.esa.int/Education/Space_In_Bytes/ATV_a_very_special_delivery_-_Lesson_notes
Author: Martin Jediny
Usage Terms: Creative Commons Attribution-Share Alike 3.0
License: CC-BY-SA-3.0
License Link: http://creativecommons.org/licenses/by-sa/3.0/
Attribution Required?: Yes
