Image: Cooling cycle
Size of this preview: 758 × 599 pixels. Other resolutions: 304 × 240 pixels | 2,408 × 1,904 pixels.
Original image (2,408 × 1,904 pixels, file size: 55 KB, MIME type: image/png)
Description: Here is a schematic with the key components in a two-phase cooling loop. The main elements are the evaporator, the condenser, the accumulator and the pump; in this system, a pre-heater is then used before the evaporator, to adjust the temperature close to the saturation point.
