Image: Edison-base-and-Type-S-fuses
Size of this preview: 800 × 427 pixels. Other resolutions: 320 × 171 pixels | 3,758 × 2,004 pixels.
Original image (3,758 × 2,004 pixels, file size: 2.7 MB, MIME type: image/jpeg)
Description: An Edison base electrical fuse (left) next to a Type S fuse (right.) The Edison base fuse is rated at 30 amps and the Type S fuse is rated at 20 amps.
Author: Gazebo
Usage Terms: Creative Commons Attribution-Share Alike 3.0
License: CC-BY-SA-3.0
License Link: http://creativecommons.org/licenses/by-sa/3.0/
Attribution Required?: Yes
