Image: Inclined plane terminology
Size of this PNG preview of this SVG file: 800 × 484 pixels. Other resolution: 320 × 194 pixels.
Original image (SVG file, nominally 1,501 × 909 pixels, file size: 6 KB)
Description: Diagram showing terminology used in describing inclined planes. The horizontal length is called the "'Run". The difference in height between bottom of plane and top is called "Rise". The length of the ramp itself is often called "slant length".
Usage Terms: Public domain
