Image: RBMK Reaktor ChNPP-4
Size of this PNG preview of this SVG file: 600 × 600 pixels. Other resolution: 240 × 240 pixels.
Original image (SVG file, nominally 2,408 × 2,408 pixels, file size: 20 KB)
Description: RBMK-Core of Chernobyl-4: Positions of control rods (insertion depth in centimeters) approximately 1min30s before the explosion on Saturday, 26. April 1986, last signal of SKALA control system at 1:22:30 h. gre (167) control rods blue: (12) LAR Rod yellow: (32) shortened absorber rods inserted from below the reactor core grey: (1661) pressure tubes red: (12) automatic control rods
Usage Terms: Public domain
