Lockheed SR-71 Blackbird facts for kids

Quick facts for kids SR-71 "Blackbird"
An SR-71B trainer over the Sierra Nevada Mountains of California in 1994. The raised second cockpit is for the instructor.
Role	Strategic reconnaissance aircraft
National origin	United States
Manufacturer	Lockheed, Skunk Works division
Designer	Clarence "Kelly" Johnson
First flight	22 December 1964
Introduction	January 1966
Retired	1998 (USAF), 1999 (NASA)
Status	Retired
Primary users	United States Air Force NASA
Number built	32
Unit cost	$34 million
Developed from	Lockheed A-12

The SR-71 Blackbird is a supersonic reconnaissance aircraft. It was built by Lockheed's "Skunk Works" in the 1960s for the United States Air Force (USAF). In other words, it was a spy plane.

Design

The Blackbird was designed to fly at more than Mach 3 – three times the speed of sound. This meant it would become very hot during flight. To help with this, most of the aircraft was made of titanium. Radar absorbing material was also used to make the aircraft more difficult to detect.

SR-71 Blackbird used a special fuel called JP-7. Before the flight, the fuel tanks used to leak. This is because at ground altitude the tolerances (distance between parts of the fuel tank) were larger than at the plane's cruising altitude. Once in the air, because of the speed and air resistance, the parts became very hot. Because of this heat, the distance between the parts shrank stopping the loss of fuel.

The aircraft also had cameras and radars fitted to take photographs of targets.

History

The first Blackbird flight happened on December 22, 1964 in Palmdale, California. In January 1966, the first aircraft entered service with the USAF. No aircraft were lost in war but one crashed in an accident in 1969. Only 32 aircraft were built. Its final flight was on March 6, 1990, Blackbird S/N 61-7972. The SR-71 program was retired from service in 1998.

Records

The aircraft flew at an altitude of over 80,000 feet (24,000 m) and at speeds over 2,190 miles per hour (3,520 km/h). It held the world record for the jet-powered flight, flying at Mach 3.2. The record was broken in March 2004 by NASA's X-43A aircraft.

Specifications (SR-71A)

Data from Lockheed SR-71 Blackbird

General characteristics

• Crew: 2; Pilot and reconnaissance systems officer (RSO)
• Length: 107 ft 5 in (32.74 m)
• Wingspan: 55 ft 7 in (16.94 m)
• Height: 18 ft 6 in (5.64 m)

• Wheel track: 16 ft 8 in (5 m)
• Wheelbase: 37 ft 10 in (12 m)
• Wing area: 1,800 sq ft (170 m²)
• Aspect ratio: 1.7
• Empty weight: 67,500 lb (30,617 kg)
• Gross weight: 152,000 lb (68,946 kg)
• Max takeoff weight: 172,000 lb (78,018 kg)
• Fuel capacity: 12,219.2 US gal (10,174.6 imp gal; 46,255 L) in 6 tank groups (9 tanks)
• Powerplant: 2 × Pratt & Whitney J58 (JTllD-20J or JTllD-20K) continuous-bleed afterburning turbojets, 25,000 lbf (110 kN) thrust each


JTllD-20J 32,500 lbf (144.57 kN) wet (fixed inlet guidevanes)

JTllD-20K 34,000 lbf (151.24 kN) wet (2-position inlet guidevanes)

Performance

• Maximum speed: 1,910 kn (2,198 mph; 3,537 km/h) at 80,000 ft (24,000 m)
• Maximum speed: Mach 3.32
• Ferry range: 2,824 nmi (3,250 mi; 5,230 km)
• Service ceiling: 85,000 ft (26,000 m)
• Rate of climb: 11,820 ft/min (60.0 m/s)
• Wing loading: 84 lb/sq ft (410 kg/m²)
• Thrust/weight: 0.44

Avionics
3,500 lb (1,588 kg) of mission equipment

• Itek KA-102A 36–48 in (910–1,220 mm) camera
• SIGINT and ELINT equipment in the following compartments

• A - nose radar
• D - right chine bay
• E - electronics bay
• K - left forward mission bay
• L - right forward mission bay
• M - left forward mission bay
• N - right forward mission bay
• P - left aft mission bay
• Q - right aft mission bay
• R - radio equipment bay
• S - left aft mission bay
• T - right aft mission bay

Images for kids

•

  SR-71 Blackbird assembly line at Skunk Works

•

  Forward cockpit

•

  D-21]] drone on top

•

  Water vapor is condensed by the low-pressure vortices generated by the chines outboard of each engine inlet.

•

  Schlieren flow visualization at unstart of axisymmetric inlet at Mach 2

•

  A Pratt & Whitney J58 (JT11D-20) engine on open display at Evergreen Aviation Museum

•

  A preserved AG330 start cart

•

  An SR-71 refueling from a KC-135Q Stratotanker during a flight in 1983

•

  The SR-71 Defensive System B

•

  SR-71 pilot in full flight suit

•

  The crew of a NASA Lockheed SR-71 Blackbird standing by the aircraft in their pressurized flight suits, 1991

•

  Early project Habu logo

•

  SR-71A (2) and SR-71B trainer, Edwards AFB, CA, 1992

•

  View from the cockpit at 83,000 feet (25,000 m) over the Atlantic Ocean

•

  Yeilding}} and RSO Lt. Col. Joseph T. "JT" Vida, 6 March 1990.

•

  SR-71B on display at the Air Zoo

•

  SR-71 at Pima Air & Space Museum, Tucson, Arizona

•

  Close-up of the SR-71B operated by NASA's Dryden Flight Research Center, Edwards AFB, California

•

  SR-71A at the National Museum of the United States Air Force

•

  Detail of SR-71A at the Museum of Aviation, Robins AFB

•

  Orthographically projected diagram of the SR-71B trainer model

•

  SR-71 epoxy asbestos composite areas
